Technical Specifications
| Capacity | 1 Phase - 1 to 20 KVA, 3 Phase - 3 to 500 KVA | |
| INPUT | Technology | IGBT Based PWM Static Voltage Stabilizer |
| Frequency | 46 - 55 Hz | |
| Voltage Range | 300 to 500 / 340 to 480 / 360 to 470 | |
| Protection MCB/MCCB | Provided | |
| OUTPUT | Voltage | 400/415 VAC |
| Voltage Regulation | +/-1% | |
| Response Time | 20 mSec | |
| Rate of correction | 2000 - 6000 V / Sec Depend upon Input Voltage Range | |
| Output Waveform Distortion | NIL | |
| 5 _ Effect of Power factor | NIL | |
| Duty Cycle | 100 % continuous | |
| Over Load | 110% for 30 Sec | |
| Efficiency | > 97% (Full load) | |
| Contactor | Available | |
| Manual Bypass Switch | Available | |
| Auto Bypass | Available | |
| Short Circuit | Provided | |
| PROTECTION | Input Over Voltage | Above the voltage Range 20V |
| Input Under Voltage | Below the voltage Range 20V | |
| Output Over Voltage | 415V + 5% | |
| Output Under Voltage | 415V - 5% | |
| Over Load | Electronic Over load Trip with Time Delay | |
| Single Phase Prevention | Provided | |
| Phase Reversal | Provided | |
| Surge Protection class 2 | Provided | |
| DISPLAY | LCD Display | 20 * 4LCD Display |
| Voltage | Input & Output Voltage - 1 phase & 3 phase | |
| Current & Frequency | Output Current -3 phase & Frequency | |
| Visual Annunciation | Input & Output Over Voltage & Under Voltage, Overload, | |
| Phase Reversal, Error Log, Temperature Cut off | ||
| Input Norma | Green LED | |
| Output Normal | Green LED | |
| Phase Fault | Red LED | |
| Over Load | Red LED | |
| Menu Key | To View Parameter | |
| Start Key | To Switch ON Output load | |
| Stop Key | To Switch OFF Output load | |
| Log Key | To View Error log | |
| ENVIRONMENTAL | Ambient Temperature | 50°C |
| Ingress Protection | IP -20 | |
| Cooling Methode | Forced Air Cooled | |
| Mounting WheelsColor | Castor Wheels with 2 Brakes | |
| Color | Cabinet -RAL 9005 & Front Display Door RAL 7040 |
